Omada 28-Port Gigabit Easy Managed Switch with 24-Port PoE+ ES228GP

Omada 28-Port Gigabit Easy Managed Switch with 24-Port PoE+ ES228GP

Omada 28-Port GigabitEasy ManagedSwitchwith 24-Port PoE+

ES228GP

28× Gigabit Ports(24× PoE+, 2× RJ45,2× SFP) 250W Total PoEBudget* Easy Centralized Management△ Up to 820ft PoE Transmission** Remote CameraReboot† TrafficSeparation TrafficPrioritization Automatic Loop Prevention

Omada Central Essentials — A Free and Easy Cloud-Based Network
Management

Omada Central Essentials is a free, easy-to-use version of the
Omada Central.It provides cloud-based centralized management and monitoring
for the Omada networking system, covering access points,
switches, and gateways, ideal for surveillance networks and
small businesses. Learn More > Lifetime FreeCloud WithoutAdditional Fees Manage andMonitor Anytimevia App or Web UnlimitedManagement Scalefor Multiple Sites ComprehensiveManagedPortfolio Super-Easy Setupwith AutomaticDevice Identificationand ZTP Easy-to-UseNetworking for Surveillance Including Remote CameraReboot Free VideoMonitoring IncludingThird-Party Camera Management△ Topology, Site Map,and Troubleshooting Tools for Efficient Maintenance

Abundant Functions for Reliable Surveillance Networking

Transmission Distance up to 820ft (250 m)** Priority Video
Quality Guaranteed Secure Traffic Separation via Port Isolation Remote CameraReboot†

Multiple Application Scenarios

Surveillance Works with IP Cameras Wi-Fi Coverage Works with Access Points Wired Connections Works with Non-PoE Devices such as PCs and Printers

ES228GP 技術規格

連接介面	• 26× 10/100/1000 Mbps RJ45 Ports• 2× Gigabit SFP Slots• Auto-Negotiation/Auto MDI/MDIX
風扇數量	2
安裝	Desktop/Rackmount Installation
物理安全鎖	√
電源供應	100-240V~ 50/60Hz 4.0A
PoE連接埠(RJ45)	• Standard: 802.3af PoE and 802.3at PoE+ compliant• PoE Ports: 24 ports• PoE Budget: 250W available for all PoE+ ports, 30W max per port• Fast PoE & Perpetual PoE• PoE Auto Recovery‡• Up to 250m PoE transmission distance**
尺寸(長 x 寬 x 高)	17.3×7.1×1.7 in (440×180×44 mm)
突波保護	±6kV
背板頻寬	56 Gbps
封包轉發速率	41.67 Mpps
MAC位址表	8K
封包緩衝記憶體	4 Mbit
巨型訊框	15 KB
流量管理(QoS)	• Port-based/802.1p/DSCP QoS• 8 Priority Queues• Priority Schedule Mode- WRR (Weighted Round Robin)• Queue Weight Config• Bandwidth Control- Port-Based Rating Limit• Storm Control- Multiple Control Modes (kbps/pps)- Broadcast/Multicast/Unknown-Unicast Control△
L2功能	• Link Aggregation – Static Link Aggregation- Up to 4 aggregation groups and up to 8 ports per group• Loopback Detection• Flow Control- 802.3x Flow Control• Mirroring- Port Mirroring- One-to-One- Many-to-One- Ingress/Egress/Both• Port Statistics- Port Mirror Status- Trafffc Statistics• 802.1ab LLDP
L2 群播	• IGMP Snooping- IGMP v1/v2/v3 Snooping- Fast Leave
VLAN	• MTU VLAN• Port-Based VLAN• 802.1Q Tag VLAN- Max 32 VLAN Groups- 4K VID
傳輸模式	Store-And-Forward
Omada App	Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
集中化管理	• Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller
雲端存取	Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
零接觸監管	Yes. Requires the use of Omada Cloud-Based Controller
管理功能	• Web-based GUI• DHCP Client• Cable Diagnostics• Automatic Device Discovery†• Batch Configuration†• Batch Firmware Upgrading†• Unified Configuration†
認證	FCC, CE, RoHS
包裝內容	• ES228GP• Power Cord• Mounting Brackets• Rubber Feet• Screws• Installation Guide
環境	• Operating Temperature: -5℃~45℃ (23℉~113℉)• Storage Temperature: -40℃~70℃ (-40℉~158℉)• Operating Humidity: 10%~90% non-condensing• Storage Humidity: 5%~90% non-condensing
