Omada4G+Cat6Gigabit Rackmount DSLGateway
DR3220v-4G Super VDSL(Up to 350 Mbps)† VDSL2/ADSL2+/ADSL2/ADSLCompatibility 4G+ Cat6 Up to 300Mbps* 2× Nano SIM for 4G/LTE Failover 5× Gigabit Ports(1× Combo SFP/RJ45 WAN/LAN, 4× RJ45 LAN) IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE/SSL VPN VoIP Support CentralizedManagement Load BalancingBetween DSL,Ethernet WAN and 4G Easy & Flexible Installation The integrated DSL port supports Super VDSL(VDSL2 35b)and is compatible with VDSL2/ADSL2+/ADSL2/ADSL connections. Compatibility with the leading ISPs provides idealIP-basedconnections for any small business. DR3220v-4G’s compatible with Super VDSL (VDSL2 Profile 35b), Ethernet access, 4G access, and 4G/3G USB modems. Its Gigabit LAN/WAN port accepts connections from cable or fiber modems, and the USB 3.0 port supports 4G/3G dongles for a solid main or backup internet connection. Centralized cloud management for Omada gateways, switches, and access points across multiple sites, with the Omada cloud-based controller offering the Essentials version of cloud services for free, reducing maintaince costs.Δ SSL/ IPSec / GRE / WireGuard / PPTP / L2TP VPN & OpenVPN easily build secure VPN tunnels for secure Internet browsing, communication between different branches, or enabling remote work or study from home.
DR3220V-4G 技術規格
| 存取控制 | Source/Destination IP Based Access Control |
|---|---|
| 過濾 | • Web Group Filtering**• URL Filtering• Web Security** |
| ARP檢測 | • Sending GARP Packets• ARP Scanning**• IP-MAC Binding |
| 攻擊防禦 | • TCP/UDP/ICMP Flood Defense• Block TCP Scan (Stealth FIN/Xmas/Null)• Block Ping from WAN |
| 連接介面 | • 1 Combo Gigabit SFP/RJ45 Port (1 SFP WAN/LAN Port + 1 WAN/LAN Port)• 4 × RJ45 Gigabit LAN Ports• 1 DSL Port• 2 FXS Ports |
| 按鈕 | Reset Button |
| 電源供應 | 100-240V/50-60Hz 0.6A |
| 插槽 | 1*USB 3.0 (supports USB LTE dongle and USB Storage) |
| 快閃記憶體 | 256MB NAND |
| DRAM | 512MB DDR4 |
| 尺寸(長 x 寬 x 高) | 11.6 × 7.1 × 1.7 in (294 × 180 × 44 mm) (Antenna dimensions notincluded) |
| 天線 | LTE: Two 3dBi omnidirectional detachable antennas |
| SIM卡插槽 | 1 Dual-SIM Nano SIM slot (4G+ Cat6) |
| 安裝 | Desktop/ Rack-mounting |
| 最大功耗 | • 8.55 W (No Link)• 24.4 W (Full load + USB ) |
| GRE | Only in Standalone Mode |
| WireGuard VPN | ✔ |
| 同步連線數 | 150,000 |
| 每秒新增連線數 | 4,050 |
| NAT (靜態 IP) | 937.2 Mbps/936.1Mbps |
| NAT(DHCP) | 945.8 Mbps /940.6Mbps |
| NAT(PPPoE) | 942.9 Mbps/942.9Mbps |
| NAT (L2TP) | 837.4 Mbps / 881.5Mbps |
| NAT (PPTP) | 803.0 Mbps / 910.5 Mbps |
| IPsec VPN 吞吐量 | • ESP-SHA1-AES256: 526.6Mbps• ESP-SHA256-AES256: 543.3Mbps• ESP-SHA384-AES256: 549.0Mbps• ESP-SHA512-AES256: 561.7Mbps |
| OpenVPN | • OpenVPN Server• OpenVPN Client (5)§• 55 OpenVPN Tunnels• “Certificate + Account” Mode• Full Mode |
| L2TP VPN 吞吐量 | Unencrypted: 909.4 MbpsEncrypted: 494.9Mbps |
| PPTP VPN 吞吐量 | Unencrypted: 897.5 MbpsEncrypted: 190.8 Mbps |
| 66 Byte 封包轉發率 | 1,453,489 pps / 1,453,488 pps |
| 1,518 Byte 封包轉發率 | 81274 pps/ 91275 pps |
| WAN連線類型 | • Static IP• Dynamic IP• PPPoE (supports MRU Configuration)• PPTP• L2TP |
| 複製MAC位址 | Modify WAN Address |
| DHCP | • DHCP Server• DHCPv6 PD Server (only in Standalone Mode)• DHCP Options Customization• DHCP Address Reservation• Multi-IP Interfaces• Multi-Net DHCP |
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| 頻寬管理 | IP-based Bandwidth Control |
| 負載平衡 | • Intelligent Load Balance• Application Optimized Routing• Link Backup (Timing, Failover)• Online Detection |
| NAT | • One-to-One NAT• Multi-Net NAT• Virtual Server• Port Triggering**• NAT-DMZ• FTP/H.323/SIP/IPSec/PPTP ALG• UPnP |
| 連線數限制(Session Limit) | IP-based Session Limit |
| SSL VPN | 50 Tunnels |
| IPsec VPN | • 100 IPSec VPN Tunnels• LAN-to-LAN, Client-to-LAN• Main, Aggressive Negotiation Mode• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm• IPsec Failover• IKE v1/v2• MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm• NAT Traversal (NAT-T)• Dead Peer Detection (DPD)• Perfect Forward Secrecy (PFS) |
| PPTP VPN | • PPTP VPN Server• PPTP VPN Client (10)§• 50 Tunnels• PPTP with MPPE Encryption |
| L2TP VPN | • L2TP VPN Server• L2TP VPN Client (10)§• 50 Tunnels• L2TP over IPSec |
| Omada App | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| 集中化管理 | • Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller |
| 雲端存取 | Yes. Require the use of Omada Controller. |
| 服務 | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
| 維護 | • Web Management Interface• Remote Management• Export & Import Configuration• SNMP v1/v2c/v3• Diagnostics (Ping & Traceroute)• NTP Synchronize1• Port Mirroring• CLI (only in Standalone Mode)• Syslog Support• TR-069 (data models of TR-098 and TR-181 are supported) |
| 零接觸監管 | Yes. Require the use of Omada Controller. |
| 預設啟用的網路服務 | Web ServerManage and configure device through web (HTTP/HTTPS)• Port: 80/443 Protocol: TCP_____________________________________________________VOIP ServerMonitor SIP messages• Port: 5060 Protocol: UDP_____________________________________________________DHCP ServerHandle DHCP packets• Port: 67 Protocol: UDP_____________________________________________________DNSHandle DNS packets• Port: 53 Protocol: TCP/UDP |
| 認證 | CE, RoHS |
| 包裝內容 | • DR3220v-4G• Power Cord• Ethernet Cable• Phone Cable• Rubber Feet• SIM Card Eject Pin• Rackmount Kit• Antenna Extension Base• Quick Installation Guide |
| 系統需求 | • Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows7/8/8.1/10/11• MAC OS, NetWare, UNIX or Linux |
| 環境 | • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)• Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)• Operating Humidity: 10% to 90% non-condensing• Storage Humidity: 5% to 90% non-condensing |
