Omada 52-Port Gigabit Smart Switch with 32-Port PoE+ SG2452LP
Member優惠價：$0
🚚 配送方式：
- • 香港本地訂單：購物滿HK$2,000, 免費送貨!
- • 澳門地區訂單：順豐到付 (運費由買家承擔)
🎧 如有技術或貨存查詢
WhatsApp 查詢Omada 52-Port Gigabit Smart Switch with 32-Port PoE+ SG2452LP
Omada 52-Port GigabitSmart Switch with32-Port PoE+
SG2452LP 48× Gigabit RJ45 Ports(32× PoE+),4× Gigabit SFP Slots 230 W TotalPoE Budget* Fanless Design forSilent Operation Zero-TouchProvisioning† CentralizedManagement† OmadaApp† StaticRouting TrafficSeparation 32× Gigabit RJ45 Ports Up to PoE per Port Total PoE Power* Compatible with PoE and non-PoE devices AccessPoints IPCameras 4KVedio Network VideoRecorder ThinClients Ensures the fast way Lightning-fast aggregation switching Remotely manage your access points, switches, and gateways across multiple sites all from a single interface. Works with IP Cameras Works with IP Phones Works with Access Points Works with Non-PoE Devices such as PCs and Printers
SG2452LP 技術規格
| 連接介面 | • 32× 10/100/1000 Mbps PoE+ RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)• 16× 10/100/1000 Mbps non-PoE RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)• 4× Gigabit SFP Slots |
|---|---|
| 風扇數量 | Fanless |
| 物理安全鎖 | √ |
| 電源供應 | 100-240 V AC~50/60 Hz |
| PoE連接埠(RJ45) | • Standard: 802.3at/af compliant• PoE+ Ports: 32 Ports (up to 30 W PoE Output per Port)• PoE Power Budget: 230 W* |
| 尺寸(長 x 寬 x 高) | 17.3×13.0×1.7 in (440×330×44 mm) |
| 安裝 | Rack Mountable |
| 最大功耗 | 304.5W (110 V/60 Hz) (with 230 W PD connected) |
| 最大散熱量 | 1035.4 BTU/hr (110 V/60 Hz) (with 230 W PD connected) |
| 背板頻寬 | 104 Gbps |
| 封包轉發速率 | 77.37 Mpps |
| MAC位址表 | 16 K |
| 封包緩衝記憶體 | 12 Mbit |
| 巨型訊框 | 9 KB |
| 流量管理(QoS) | • 802.1p CoS/DSCP priority• 8 priority queues• Priority Schedule Mode: SP (Strict Priority), WRR (Weighted Round Robin)• Queue Weight Config• Bandwidth Control: Port/Flow-based Rating Limit• Smoother Performance• Storm Control: Multiple Control Modes(kbps/ratio), Broadcast/Multicast/Unknown-Unicast Control |
| L2與L2+功能 | • 16 IP Interfaces: Support IPv4/IPv6 Interface• Static Routing: 32 IPv4/IPv6 Static Routes• DHCP Server• DHCP Relay- DHCP Interface Relay- DHCP VLAN Relay• DHCP L2 Relay• Static ARP• Proxy ARP• Gratuitous ARP• Link Aggregation• Spanning Tree Protocol• Loopback Detection• 802.3x Flow Control• Mirroring• Device Link Detect Protocol (DLDP)• 802.1ab LLDP/ LLDP-MED |
| L2 群播 | • 511 IPv4, IPv6 shared multicast groups• IGMP Snooping• Multicast VLAN Registration (MVR)• Multicast Filtering• Limited IP Multicast (256 profiles and 16 entries per profile) |
| 進階功能 | • Automatic Device Discovery†• Batch Configuration†• Batch Firmware Upgrading†• Intelligent Network Monitoring†• Abnormal Event Warnings†• Unified Configuration†• Reboot Schedule† |
| VLAN | • VLAN Group: Max. 4K VLAN Groups• 802.1Q tag VLAN• MAC VLAN: 12 Entries• Protocol VLAN• GVRP• Voice VLAN |
| 存取控制列表(ACL) | • Support up to 230 entries• Time-based ACL• MAC ACL• IP ACL• IPv6 ACL• Combined ACL• Rule Operation: Permit/Deny• Policy Action- Mirroring- Redirect- Rate Limit- QoS Remark• ACL Rules Binding- Port Binding- VLAN Binding |
| 安全性 | • IP-MAC-Port Binding• AAA• 802.1X- Port based authentication- MAC (Host) based authentication- Authentication Method includes PAP/EAP-MD5- MAB- Guest VLAN- Radius authentication and accountability support• IP/IPv6-MAC Binding- 512 Binding Entries- DHCP Snooping- DHCPv6 Snooping- ARP Inspection- ND Detection• IP Source Guard- 253 Entries- Source IP+Source MAC• IPv6 Source Guard- 183 Entries- Source IPv6 Address+Source MAC• DoS Defend• Static/Dynamic/Permanent Port Security: Up to 64 MAC addresses per port• Broadcast/Multicast/Unicast Storm Control: kbps/ratio control mode• Port Isolation• Secure web management through HTTPS with SSLv3/TLS 1.2• Secure Command Line Interface (CLI) management with SSHv1/SSHv2• IP/Port/MAC-based access control |
| IPv6 | • IPv6 Static Routing and ACL• IPv6 Dual IPv4/IPv6• IPv6 Interface• Multicast Listener Discovery (MLD) Snooping• IPv6 neighbor discovery (ND)• Path maximum transmission unit (MTU) discovery• Internet Control Message Protocol (ICMP) version 6• TCPv6/UDPv6• IPv6 applications: DHCPv6 Client, Ping6, Tracert6, Telnet(v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP |
| MIBs | • MIB II (RFC1213)• Bridge MIB (RFC1493)• P/Q-Bridge MIB (RFC2674)• Radius Accounting Client MIB (RFC2620)• Radius Authentication Client MIB (RFC2618)• Remote Ping, Traceroute MIB (RFC2925)• Support TP-Link private MIBs• RMON MIB(RFC1757, rmon 1,2,3,9) |
| Omada App | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| 集中化管理 | • Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller |
| 雲端存取 | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| 零接觸監管 | Yes. Requiring the use of Omada Cloud-Based Controller. |
| 管理功能 | • Web-based GUI• Command Line Interface (CLI) through telnet• SNMPv1/v2c/v3• SNMP Trap/Inform• RMON (1,2,3,9 groups)• SDM Template• DHCP/BOOTP Client• Dual Image, Dual Configuration• CPU Monitoring• Cable Diagnostics• EEE• SNTP• System Log |
| 認證 | CE, FCC, RoHS |
| 包裝內容 | • SG2452LP• Power Cord• Quick Installation Guide• Rackmount Kit• Rubber Feet |
| 系統需求 | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| 環境 | • Operating Temperature: 0–40 ℃ (32–104 ℉);• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing |
產品資源
| Brands | Omada |
|---|
