Omada 8-Port 2.5G BASE-T Easy Managed Switch with 2 10GE SFP+ Slots ES206XPP-M2
Member優惠價：$0
🚚 配送方式：
- • 香港本地訂單：購物滿HK$2,000, 免費送貨!
- • 澳門地區訂單：順豐到付 (運費由買家承擔)
🎧 如有技術或貨存查詢
WhatsApp 查詢Omada 8-Port 2.5G BASE-T Easy Managed Switch with 2 10GE SFP+ Slots ES206XPP-M2
ES206XPP-M2 技術規格
| 連接介面 | • 8× 2.5 Gbps RJ45 Ports• 2× 10 Gbps SFP+ Slots• Auto-Negotiation/Auto MDI/MDIX |
|---|---|
| 風扇數量 | Fanless |
| 安裝 | • Desktop• Wall Mount |
| 物理安全鎖 | √ |
| 電源供應 | DC Power Adapter (Output: 12 VDC / 1.5 A) |
| 尺寸(長 x 寬 x 高) | 8.2 × 5.0 × 1.0 in (209 × 126 × 26 mm) |
| 突波保護 | ±6 kV |
| 背板頻寬 | 80 Gbps |
| 封包轉發速率 | 59.52 Mpps |
| MAC位址表 | 16K |
| 封包緩衝記憶體 | 640 KB |
| 巨型訊框 | 10 KB |
| 流量管理(QoS) | • Port-based/802.1p/DSCP QoS• 8 Priority Queues• Priority Schedule Mode- WRR (Weighted Round Robin)• Queue Weight Config• Bandwidth Control- Port-Based Rating Limit• Storm Control- Multiple Control Modes (kbps/pps)- Broadcast/Multicast/Unknown-Unicast Control△ |
| L2功能 | • Static Link Aggregation• Loop Prevention / Loopback Detection• Flow Control- 802.3x Flow Control• Mirroring- Port Mirroring- One-to-One- Many-to-One- Ingress/Egress/Both• Port Statistics- Port Mirror Status- Traffic Statistics• 802.1ab LLDP |
| L2 群播 | • IGMP Snooping- IGMP v1/v2/v3 Snooping- Fast Leave |
| VLAN | • MTU VLAN• Port-Based VLAN• 802.1Q Tag VLAN- Max 32 VLAN Groups- 4K VID |
| 傳輸模式 | Store-And-Forward |
| Omada App | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| 集中化管理 | • Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller |
| 雲端存取 | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| 零接觸監管 | Yes. Requires the use of Omada Cloud-Based Controller |
| 管理功能 | • Web-based GUI• DHCP Client• Cable Diagnostics• Automatic Device Discovery†• Batch Configuration†• Batch Firmware Upgrading†• Unified Configuration† |
| 認證 | FCC, CE, RoHS |
| 包裝內容 | • ES210X-M2• Power Adapter• Rubber Feet• Installation Guide |
| 環境 | • Operating Temperature: -5℃~40℃ (23℉~104℉)• Storage Temperature: -40℃~70℃ (-40℉~158℉)• Operating Humidity: 10%~90% non-condensing• Storage Humidity: 5%~90% non-condensing |
