Omada 8-Port Gigabit Unmanaged Desktop Switch with 8-Port PoE+ DS108GP
🚚 配送方式：
- • 香港本地訂單：購物滿HK$2,000, 免費送貨!
- • 澳門地區訂單：順豐到付 (運費由買家承擔)
🎧 如有技術或貨存查詢
WhatsApp 查詢Omada 8-Port Gigabit Unmanaged Desktop Switch with 8-Port PoE+ DS108GP
Omada 8-PortGigabit Unmanaged Desktop Switchwith 8-PortPoE+
65 W PoEBudget* Long-Range PoE+(250m**) PoE AutoRecovery Intelligent PowerManagement Desktop orWall-Mounting Plugand Play Fanless Design forSilent Operation Durable MetalCasing Compliant with the IEEE 802.3af/at PoE standards, the switch supports a total PoE power budget of 65 W with 30 W maxper PoE+ port. When total power consumption exceeds 65 W, the intelligent power management will cut the lowerpriority ports power to protect devices from damage. AccessPoint IPPhone IPCamera 4KVideo Network VideoRecorder Computer With extend mode, the PoE transmission distance reaches up to 250 m**—perfect for IP Camera deployment in large areas. Recovery mode helps automatically detect and reboot PD devices, suchas cameras and APs, when they fall offline or gounresponsive—allwithoutneeding manual monitoring and restarts. With extend mode, the PoE transmission distance reaches up to 250 m** —perfect for IP Camera deployment in large areas. Recovery mode helps automatically detect and reboot PD devices, such as cameras and APs, when they fall offline or gounresponsive—allwithout needing manual monitoring and restarts. IP Phone IP Camera Access Point Internet Router
DS108GP 技術規格
| 連接介面 | • 8× 10/100/1000 Mbps RJ45 Ports• AUTO Negotiation• AUTO MDI/MDIX |
|---|---|
| 網路連接線 | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)EIA/TIA-568 100Ω STP (maximum 100m)• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)EIA/TIA-568 100Ω STP (maximum 100m)• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)EIA/TIA-568 100Ω STP (maximum 100m) |
| 風扇數量 | Fanless |
| 物理安全鎖 | Yes |
| 外接電源供應器 | External Power Adapter(Output: 53.5VDC / 1.31A) |
| 封包轉發速率 | 11.904 Mpps |
| PoE連接埠(RJ45) | • Standard: 802.3 af/at compliant• PoE Ports: Ports 1–8• Power Supply: 65 W |
| MAC位址表 | 4K |
| 巨型訊框 | 16 KB |
| 交換容量 | 16 Gbps |
| 尺寸(長 x 寬 x 高) | 6.2×4.0×1.0 in (158×101×25 mm) |
| 最大功耗 | • 4.59 W (220/50 Hz no PD connected)• 75.75 W (220/50 Hz with 65 W PD connected) |
| 最大散熱量 | • 15.66 BTU/h (no PD connected)• 258.46 BTU/h (with 65 W PD connected) |
| 進階功能 | • Compatible With IEEE 802.3af/at Compliant PDs• IGMP Snooping• Mac Address Auto-Learning And Auto-Aging• IEEE802.3x Flow Control• 802.1p/DSCP QoS• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)• PoE Auto Recovery (Ports 1-8) |
| 傳輸模式 | Store-And-Forward |
| 認證 | CE, FCC, RoHS |
| 包裝內容 | • DS108GP• Power Adapter• Installation Guide |
| 環境 | • Operating Temperature: 0–40 ℃ (32–104 ℉);• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing |
產品資源
| Brands | Omada |
|---|
