Omada Access 6-Port Gigabit Switch with 4-Port PoE+ SG2206MP
Member優惠價：$0
🚚 配送方式：
- • 香港本地訂單：購物滿HK$2,000, 免費送貨!
- • 澳門地區訂單：順豐到付 (運費由買家承擔)
🎧 如有技術或貨存查詢
WhatsApp 查詢Omada Access 6-Port Gigabit Switch with 4-Port PoE+ SG2206MP
OmadaAccess6-Port Gigabit PoE+ Switch
SG2206MP 5× Gigabit Ports(4× PoE+), 1× SFP Slot 63W TotalPoE Budget* Fanless Design forSilent Operation Centralized Management† TrafficSeparation AccessControl StaticRouting OmadaApp† 4× Gigabit PoE+ RJ45 Ports Up to 30W per PoE+ Port Total 63W PoE Power Budget* Compatible with 802.3af/at PoE and non-PoE devices Access Point IPPhone IPCamera Gateway/AggregationSwitch Works with Access Points Works with IP Cameras Works with IP Phones Works with Non-PoE Devices such as PCs and Printers
SG2206MP 技術規格
| 連接介面 | • 4× 10/100/1000 Mbps PoE+ RJ45 Ports• 1× 10/100/1000 Mbps RJ45 Port• 1× Gigabit SFP Slot |
|---|---|
| 物理安全鎖 | √ |
| 電源供應 | 53.5 VDC / 1.31 A |
| PoE連接埠(RJ45) | • Standard: 802.3at/af compliant• PoE+ Ports: 4 Ports• PoE Power Budget: 63 W*• Fast PoE• Perpetual PoE |
| 尺寸(長 x 寬 x 高) | 6.2 × 4.0 × 1.0 in (158 × 100.7 × 25.4 mm) |
| 安裝 | Desktop / Wall Mounting |
| 最大功耗 | 73.7 W (110V/60Hz) (with 63 W PD connected) |
| 最大散熱量 | 250.4 BTU/hr (110V/60Hz) (with 63 W PD connected) |
| 背板頻寬 | 12 Gbps |
| 封包轉發速率 | 8.93 Mpps |
| MAC位址表 | 8K |
| 封包緩衝記憶體 | 4.1 Mbit |
| 巨型訊框 | 9 KB |
| 流量管理(QoS) | • 802.1p CoS/DSCP priority• 8 priority queues• Priority Schedule Mode- SP (Strict Priority)- WRR (Weighted Round Robin)• Queue Weight Config• Bandwidth Control- Port/Flow based Rating Limit• Storm Control- Multiple Control Modes(kbps/ratio)- Broadcast/Multicast/Unknown-Unicast Control |
| L2與L2+功能 | • 16 IP Interfaces: Support IPv4/IPv6 Interface• Static Routing: 32 IPv4/IPv6 Static Routes• DHCP Server• DHCP Relay- DHCP Interface Relay- DHCP VLAN Relay• DHCP L2 Relay• Static ARP• Proxy ARP• Gratuitous ARP• Link Aggregation• Spanning Tree Protocol• Loopback Detection• 802.3x Flow Control• Mirroring• Device Link Detect Protocol (DLDP)• 802.1ab LLDP/ LLDP-MED• Spanning Tree- STP (802.1d)- RSTP (802.1w)- MSTP (802.1s)- STP Security: TC Protect, BPDU Filter/Protect, Root Protect |
| L2 群播 | • 511 IPv4, IPv6 shared multicast groups• IGMP Snooping• Multicast VLAN Registration (MVR)• Multicast Filtering• Limited IP Multicast (256 profiles and 16 entries per profile) |
| 進階功能 | • Automatic Device Discovery†• Batch Configuration†• Batch Firmware Upgrading†• Intelligent Network Monitoring†• Abnormal Event Warnings†• Unified Configuration†• Reboot Schedule† |
| VLAN | • VLAN Group- Max. 4K VLAN Groups• 802.1Q tag VLAN• MAC VLAN: 16 Entries• Protocol VLAN• GVRP• Voice VLAN |
| 存取控制列表(ACL) | • Support up to 230 entries• Time-Range• Time-based ACL• MAC ACL• IP ACL• IPv6 ACL• Combined ACL• Rule Operation: Permit/Deny• Policy Action- Mirroring- Redirect- Rate Limit- QoS Remark• ACL Rules Binding- Port Binding- VLAN Binding |
| 安全性 | • IP-MAC-Port Binding• AAA• 802.1X- Port-based authentication- MAC (Host) based authentication- Authentication Method includes PAP/EAP-MD5- MAB- Guest VLAN- Support Radius authentication and accountability• IP/IPv6-MAC Binding- 512 Binding Entries- DHCP Snooping- DHCPv6 Snooping- ARP Inspection- ND Detection- ND Snooping• IP Source Guard- 253 Entries- Source IP+Source MAC• IPv6 Source Guard- 183 Entries- Source IPv6 Address+Source MAC• DoS Defend• DHCP Filter• Static/Dynamic/Permanent Port Security- Up to 64 MAC addresses per port• Broadcast/Multicast/Unicast Storm Control- kbps/ratio control mode• Port Isolation• Secure web management through HTTPS with SSLv3/TLS 1.2• Secure Command Line Interface (CLI) management with SSHv1/SSHv2• IP/Port/MAC-based access control |
| IPv6 | • IPv6 Static Routing and ACL• IPv6 Dual IPv4/IPv6• IPv6 Interface• Multicast Listener Discovery (MLD) Snooping• IPv6 neighbor discovery (ND)• Path maximum transmission unit (MTU) discovery• Internet Control Message Protocol (ICMP) version 6• TCPv6/UDPv6• IPv6 applications- DHCPv6 Client- Ping6- Tracert6- Telnet(v6)- IPv6 SNMP- IPv6 SSH- IPv6 SSL- Http/Https- IPv6 TFTP |
| MIBs | • MIB II (RFC1213)• Bridge MIB (RFC1493)• P/Q-Bridge MIB (RFC2674)• Radius Accounting Client MIB (RFC2620)• Radius Authentication Client MIB (RFC2618)• Remote Ping, Traceroute MIB (RFC2925)• Support TP-Link private MIBs• RMON MIB(RFC1757, rmon 1,2,3,9) |
| Omada App | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| 集中化管理 | • Omada Cloud-Based Controller (Requires built-in version 5.15.22 or later)• Omada Hardware Controller (Requires built-in version 5.15.20 or later)• Omada Software Controller (Requires built-in version 5.15.20 or later) |
| 雲端存取 | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| 零接觸監管 | Yes. Requiring the use of Omada Cloud-Based Controller |
| 管理功能 | • Web-based GUI• Command Line Interface (CLI) through telnet• SNMPv1/v2c/v3• SNMP Trap/Inform• RMON (1,2,3,9 groups)• SDM Template• DHCP/BOOTP Client• Dual Image, Dual Configuration• CPU Monitoring• Cable Diagnostics• IEEE 802.1az Energy Efficient Ethernet (EEE)• SNTP• System Log• Digital Diagnostic Monitoring (DDM)• Operation Administration and Maintenance (OAM) |
| 認證 | CE, FCC, RoHS |
| 包裝內容 | • SG2206MP• Power Adapter• Power Cord• Rackmount Kit• Rubber Feet• Installation Guide |
| 系統需求 | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| 環境 | • Operating Temperature: -5–40 ℃ (23–104 ℉);• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH, non-condensing• Storage Humidity: 5–90% RH, non-condensing |
產品資源
| Brands | Omada |
|---|
