Omada AX3000 Indoor/Outdoor WiFi 6 Access Point EAP650-D30-OUTDOOR

Omada AX3000 Indoor/Outdoor WiFi 6 Access Point EAP650-D30-OUTDOOR

Omada AX3000Indoor/OutdoorWiFi 6Access Point

EAP650 D30-Outdoor WiFi 6 Speeds up to3.0 Gbps† DirectionalAntennas Focused &Ultra-RangeCoverage PoE+Support Omada Seamless Roaming and Mesh Centralized Management viaApp or Web Automatic WLANOptimization IP68 Weatherproof Enclosure The EAP650 D30-Outdoor features a durable, fully sealed IP68 weatherproof enclosure, making it dustproof and capable of withstanding submersion in water. It is ideal for warehouse environments. Durable WaterproofEnclosure Operating Temperatureof -30°C to 70°C No Ingressof Dust Warehouse Shelving Areas Storehouses Equipped with 4× built-in dual-band directional antennas with high gain to ensure the optimal WiFi experience ideal for precise and extended coverage.* Recommended Installation Height 13 ft / 4 m Recommended Coverage Length 262 ft / 80 m Higher Installation Longer Coverage Less Disruption 2.4 GHz up to 1181 ft/360 m* 5 GHz up to 2953 ft/900 m* *Based on field tests in an open, outdoor, and unobstructed environment. The number listed here is the maximum distance of one EAP650 D30-Outdoor which the client’s signal strength is ≥ -75 dBm. The real transmission range and recommended coverage may vary, according to the environment, receiving device, etc. Ensure users enjoy uninterrupted steaming when moving around by switching clients automatically to the access points with the optimal signals. Seamless Roaming On-Premises Controllers Or Or OmadaCloud-BasedController△ Omada Hardware Controller Omada Software Controller WiFi 6 Indoor/Outdoor AP EAP650 D30-Outdoor Omada PoE Switch Omada VPN Gateway Internet Cloud Access Web Browser Omada App

EAP650-D30-OUTDOOR 技術規格

連接介面	1× Gigabit Ethernet Port (supports 802.3at PoE or 48V Passive PoE)
按鈕	Reset
電源供應	• 802.3at PoE• 48V Passive PoE
功耗	• EU: 12.5W (802.3at PoE or Passive PoE)• US: 14.7W (802.3at PoE or Passive PoE)
尺寸(長 x 寬 x 高)	8.2 × 2.3 × 9.1 in (207.5 × 58 × 230 mm)
天線	Built-in Directional Antennas:• 2.4 GHz: 2× 12 dBi• 5 GHz: 2× 15 dBiBeamwidth: 30° Horizontal; 30° Vertical
藍牙	Yes
防風雨外殼	IP68
安裝	Wall/Pole/Ceiling Mount
可同時連線用戶數	250+**
無線網路標準	IEEE 802.11 a/b/g/n/ac/ax
無線網路頻率	2.4 GHz, 5 GHz
訊號速率	574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz)†
無線網路功能	• 1024-QAM• DL/UL OFDMA• Multiple SSIDs (Up to 16 SSIDs, 8 on each band)• Enable/Disable Wireless Radio• Enable/Disable SSID Broadcast• Guest Network• Automatic Channel Assignment• Transmit Power Control (Adjust Transmit Power on dBm)• QoS (WMM)• 2 × 2 (2.4 GHz & 5 GHz) DL/UL MU-MIMO• Omada Mesh§• Seamless Roaming(802.11k/v/r)§• Band Steering• Load Balance• Airtime Fairness• Beamforming• RADIUS Accounting• MAC Authentication• Reboot Schedule• Wireless Schedule• Wireless Statistics• Static IP/Dynamic IP
無線網路安全性	• Captive Portal Authentication§• Access Control• Wireless Mac Address Filtering• Wireless Isolation Between Clients• SSID to VLAN Mapping• Rogue AP Detection• 802.1X Support• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
傳輸功率	• EU: < 20 dBm (2.4GHz, EIRP); < 23dBm (5 GHz, band1 & band 2, EIRP);< 30 dBm (5 GHz,band 3, EIRP);• US: < 30 dBm (2.4 GHz); < 30 dBm (5 GHz)
Omada App	Yes
Restore & Backup	Yes
NTP	Yes
集中化管理	• Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller
雲端存取	Yes. Require the use of an Omada controller.
E-mail警示	Yes
LED 開/關 控制	Yes
管理MAC存取控制	Yes
SNMP	v1, v2c, v3
系統登入本地/遠端系統日誌	Yes
SSH	Yes
Web管理介面	Yes
多站點管理	Yes
零接觸監管	Yes. Requiring the use of Omada Cloud-Based Controller
認證	CE, FCC, RoHS
包裝內容	• Access Point EAP650 D30-Outdoor• Mounting Kits• Installation Guide• Waterproof Kit
系統需求	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
環境	• Operating Temperature: -30–70 ℃ (-22–158 ℉)• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing
