Omada AX3000 Wall Plate WiFi 6 Access Point EAP650-WALL
Member優惠價：$0
🚚 配送方式：
- • 香港本地訂單：購物滿HK$2,000, 免費送貨!
- • 澳門地區訂單：順豐到付 (運費由買家承擔)
🎧 如有技術或貨存查詢
WhatsApp 查詢Omada AX3000 Wall Plate WiFi 6 Access Point EAP650-WALL
AX3000 Wall PlateWiFi 6Access Point
EAP650-Wall WiFi 6 Speedsup to 3.0 Gbps† High-EfficiencyWiFi 6‡ 2× GigabitPorts 802.3afPoE EnhancedSecurity Centralized Cloud Management Omada Mesh &Seamless Roaming§ EasyInstallation Room-by-room connectionwith elegant appearance Stable wireless andwired connections Private and secure network accessfor every family Whole-home WiFi coveragewith seamless roaming Faster streaming anddownloading for your needs Reliable office / guest Wi-Fiin every corner 1024 QAM Long OFDM Symbol 160 MHz Channel TP-Link PoE Switch Ethernet Cable 86 mm walljunction box Standard EU walljunction box
EAP650-WALL 技術規格
| 連接介面 | • Uplink: 1× Gigabit Ethernet Port• Downlink: 1× Gigabit Ethernet Port |
|---|---|
| 物理安全鎖 | No |
| 按鈕 | Reset, LED |
| 電源供應 | 802.3af PoE |
| 功耗 | EU: 10.5 W |
| 尺寸(長 x 寬 x 高) | 3.4 × 3.4 × 1.7 in (86 × 86 × 42.2 mm) |
| 天線 | 2 Dual-Band Antennas• 2.4 GHz: 2× 3 dBi• 5 GHz: 3× 5 dBi |
| 安裝 | Wall Mounting (Screws included) |
| 覆蓋範圍 | 450ft² (40㎡)*** |
| 可同時連線用戶數 | 250+** |
| 無線網路標準 | IEEE 802.11ax/ac/n/g/b/a |
| 無線網路頻率 | 2.4 GHz and 5 GHz |
| 訊號速率 | • 5 GHz: Up to 2402 Mbps• 2.4 GHz: Up to 574 Mbps |
| 無線網路功能 | • 16 SSIDs (Up to 8 SSIDs on each band)• Enable/Disable Wireless Radio• Automatic Channel Assignment• Transmit Power Control (Adjust Transmit Power on dBm)• QoS(WMM)• Omada Mesh§• Seamless Roaming(802.11k/v/r)§• Beamforming• Rate Limit• Load Balance• Airtime Fairness• Band Steering• Reboot Schedule• Wireless Schedule• RADIUS Accounting• MAC Authentication• Wireless Statistics• Static IP/Dynamic IP |
| 無線網路安全性 | • Captive Portal Authentication§• Access Control• Wireless Mac Address Filtering• Wireless Isolation Between Clients• VLAN• Rogue AP Detection• 802.1X Support• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| 傳輸功率 | • CE:<20 dBm (2.4GHz, EIRP)<23 dBm (5GHz, EIRP ) |
| Omada App | Yes |
| 集中化管理 | • Omada Hardware Controller• Omada Software Controller• Omada Cloud-Based Controller |
| 雲端存取 | Yes. Require the use of an Omada controller. |
| E-mail警示 | Yes |
| LED 開/關 控制 | Yes |
| 管理MAC存取控制 | Yes |
| SNMP | v1, v2c, v3 |
| 系統登入本地/遠端系統日誌 | Local/Remote Syslog |
| SSH | Yes |
| Web管理介面 | HTTP/HTTPS |
| L3 管理 | Yes |
| 多站點管理 | Yes |
| 管理VLAN | Yes |
| 零接觸監管 | Yes. Requiring the use of Omada Cloud-Based Controller. |
| 認證 | CE, RoHS |
| 包裝內容 | • AX3000 Wall Plate WiFi 6 Access Point EAP650-Wall• Installation Guide• Mounting Kits |
| 系統需求 | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux |
| 環境 | • Operating Temperature: 0–40 ℃ (32–104 ℉)• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing |
產品資源
| Brands | Omada |
|---|
