Omada BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point EAP783
Member優惠價：$0
🚚 配送方式：
- • 香港本地訂單：購物滿HK$2,000, 免費送貨!
- • 澳門地區訂單：順豐到付 (運費由買家承擔)
🎧 如有技術或貨存查詢
WhatsApp 查詢Omada BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point EAP783
應用場景
具有多達 24 個 SSID 的安全訪客網絡
簡訊登入協助您的業務△
WPA3 用於無憂開放公共網絡
惡意 AP 偵測
EAP783 技術規格
| 連接介面 | 2× 10G Ethernet Ports |
|---|---|
| 按鈕 | Reset |
| 電源供應 | • 802.3bt PoE++• 12V DCNote：Power adapter is not included. |
| 功耗 | 39W |
| 尺寸(長 x 寬 x 高) | 11.0 x 11.0 x 1.8 in (280 x 280 x 46.5 mm) |
| 天線 | Internal Omni• 2.4 GHz: 4× 4 dBi• 5 GHz: 4× 5.5 dBi• 6 GHz: 4× 5 dBi |
| 藍牙 | V5.2 |
| 安裝 | Ceiling / Wall Mounting (Kits Included) |
| 覆蓋範圍 | 200㎡ (2150 ft²)§ |
| 可同時連線用戶數 | 760+** |
| 無線網路標準 | IEEE 802.11 a/b/g/n/ac/ax/be |
| 無線網路頻率 | 6 GHz, 5 GHz, and 2.4 GHz |
| 訊號速率 | • 6 GHz: Up to 11520 Mbps• 5 GHz: Up to 8640 Mbps• 2.4 GHz: Up to 1376 Mbps |
| 無線網路功能 | • MLO• 4K-QAM• 4×4 MU-MIMO DL/UL• HE320 (320 MHz Bandwidth)‡• Mesh§• AI Roaming△• Automatic Channel Selection and Power Adjustment*• BSS Coloring• UL/DL OFDMA• Load Balance• Band Steering• Beamforming• Airtime Fairness• Multiple SSIDS• Wireless Statistics• Wireless Schedule• Reboot Schedule• RADIUS Accounting• MAC Authentication• Static IP/Dynamic IP |
| 無線網路安全性 | • PPSK• VLAN• Access Control• Rogue AP Detection• Captive Portal Authentication△• Maximum number of MAC Filter: 4,000• Wireless Isolation between Clients• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE |
| 傳輸功率 | • FCC: <28 dBm (2.4 GHz)<28 dBm (5G band 1&band 4)<24 dBm (5G band 2&band 3)<28 dBm (6 GHz) |
| Omada App | Yes |
| Restore & Backup | Yes |
| 透過網頁更新韌體 | Yes |
| NTP | Yes |
| 集中化管理 | • Omada Hardware Controller (OC300)• Omada Hardware Controller (OC200)• Omada Software Controller• Omada Cloud-Based Controller |
| 雲端存取 | Yes. Require the use of OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller. |
| E-mail警示 | Yes |
| LED 開/關 控制 | Yes |
| 管理MAC存取控制 | Yes |
| SNMP | v1, v2c, v3 |
| SSH | Yes |
| Web管理介面 | Yes |
| 重量 | Net Weight:1384.6g |
| 認證 | CE, FCC, RoHS, IC |
| 包裝內容 | • EAP783• Installation Guide• Ceiling/Wall Mounting Kits |
| 環境 | • Operating Temperature: 0 °C–40 °C (32 °F–104 °F);• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);• Operating Humidity: 10%–90% non-condensing;• Storage Humidity: 5%–90% non-condensing |
產品資源
| Brands | Omada |
|---|
