Omada Campus 24-Port SFP Stackable Lite L3 Managed Switch with 4× 10G Slots SG5428XF

SG5428XF 技術規格

連接介面 • 20× 100/1000 Mbps SFP Slots• 4× Gigabit RJ45/SFP Combo Ports• 4× 1/10 Gbps SFP+ Slots*• 1× USB 2.0 Port• 1× RJ45 Console Port• 1× USB Type-C Console Port
風扇數量 1 Fan
電源供應 100-240 V~50/60 Hz
尺寸(長 x 寬 x 高) 17.3 × 8.7 × 1.7 in (440 × 220 × 44 mm)
安裝 Rackmountable
最大功耗 • 28.3 W (220V/50Hz @ 25 °C)• 28.98 W (110V/60Hz @ 25 °C)
最大散熱量 • 96.503 BTU/hr (220V/50Hz @ 25 °C)• 98.822 BTU/hr (110V/60Hz @ 25 °C)
背板頻寬 128 Gbps per Unit
堆疊 • Stacking Number: 4• Stacking Port: 10G SFP+ Slot (all uplink ports can be used as stacking ports)• Stacking Bandwidth: Up to 80 Gbps (4 stacking ports)
封包轉發速率 95.23 Mpps
MAC位址表 16 K
封包緩衝記憶體 12 Mbit
巨型訊框 9 KB
流量管理(QoS) • Class of Service- 8 Queues of Priority- Port Priority- IEEE 802.1p Priority- DSCP Priority- Queue Min-Bandwidth- Schedule Mode (SP, WRR, SP+WRR)• Bandwidth Control- Rate Limit- Storm Control• Voice VLAN• User-Defined OUI• Smoother Performance• Action for Flows- QoS remark (802.1P Remark, DSCP Remark)
L3功能 • IP Interfaces:- IPv4: Max 128, IPv6: Max 128• ARP- Static Entries 512- Dynamic Entries 3,600• ND Dynamic Entries 3,600• Static Route- IPv4: Max 512, IPv6: Max 128• Host Route- IPv4: Max 1,024, IPv6: Max 890• Network Route- IPv4: Max 1,796, IPv6: Max 450• RIP: Version v1/v2• RIPng• OSPF: Version V2/V3• Proxy ARP• DHCP Server:- Max 64 IP Pools- Max 8,000 Leases- Max 1,000 Manual Binding Entries• DHCP Relay:- Relayed Interface- Relayed VLAN
L2與L2+功能 • Link Aggregation• Spanning Tree Protocol• Port-based and VLAN-based Loopback Detection• 802.3x Flow Control• ERPS• Mirroring• RSPAN• MAC Address Table• Multicast- IGMP Snooping- MLD Snooping- L2 Multicast Table: Max 2,000- Fast Leave- Multicast VLAN Registration (MVR)- Static Multicast Groups- Multicast Filtering
進階功能 • Automatic Device Discovery†• Batch Configuration†• Batch Firmware Upgrading†• Intelligent Network Monitoring†• Abnormal Event Warnings†• Unified Configuration†• Reboot Schedule†ISP Features:• 802.3ah Ethernet Link OAM• L2PT (Layer 2 Protocol Tunneling)• Device Link Detect Protocol (DLDP)• DDM• sFlow
VLAN • Max 4K VLAN Group (802.1q VLAN)• 802.1Q Tagged VLAN• MAC VLAN Entries: 60• Multicast VLAN• Management VLAN• VLAN VPN (QinQ): Max 256 entries• GVRP• Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries• Voice VLAN• Private VLAN
安全性 • Port Isolation• CPU-Defend• ARP Inspection (Dynamic ARP Inspection)• DoS Defend• IP-MAC-Port Binding-1,024 Entries- DHCP Snooping- ARP Scanning- ARP Detection- IPv4 Source Guard• IPv6-MAC-Port Binding-1,024 Entries- DHCPv6 Snooping- ND Snooping- ND Detection- IPv6 Source Guard• DHCP Filter• Static/Dynamic Port Security- Up to 64 MAC addresses per port• Broadcast/Multicast/Unknown-unicast Storm Control- kbps/ratio control mode• 802.1X- Port base authentication- Mac base authentication- VLAN Assignment- MAB- Guest VLAN- RADIUS authentication and accountability support• AAA (including TACACS+)• Secure web management through HTTPS with SSLv3/TLS 1.2• Secure Command Line Interface (CLI) management with SSHv2• IP/Port/MAC-based access control
Omada App Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
集中化管理 • Omada Cloud-Based Controller (Requires built-in version 5.15.22 or later)• Omada Hardware Controller (Requires built-in version 5.15.20 or later)• Omada Software Controller (Requires built-in version 5.15.20 or later)
雲端存取 Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
零接觸監管 Yes. Requiring the use of the Omada Cloud-Based Controller.
管理功能 • Web-based GUI• Command Line Interface (CLI) through console port, telnet• SNMPv1/v2c/v3- Trap/Inform- RMON (1, 2, 3, 9 groups)• SDM Template• DHCP/BOOTP Client• 802.1ab LLDP/LLDP-MED• DHCP Auto Install• Dual Image, Dual Configuration• CPU Monitoring• Cable Diagnostics• Password Recovery• SNTP• System Log• IEEE 802.3az Energy Efficient Ethernet (EEE)
包裝內容 • SG5428XF Switch• Power Cords• Console Cable• Rackmount Kits• Rubber Feet• Quick Installation Guide
系統需求 Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
環境 • Operating Temperature: -5 °C to 45 °C (23 °F to 113 °F)• Storage Temperature: -40 °C to 70 ℃ (-40 ℉ to 158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing
